Brake Drum, 15 in x 4 in, 8 holes, (66 lb)
#ROC53123575002
Specifications
| Axle Capacity (lb) | 29101 kg (13200 lbs) |
| Balanced or Unbalanced | Balanced |
| Bolt Circle Diameter | 10-53/64 in (27.51 cm) |
| Bolt Hole (Number) | 8 |
| Brake Shoe Width | 4 in (10.16 cm) |
| Brake Size | 15 in x 4 in |
| Brake Surface Diameter | 15 in (38.1 cm) |
| Brake Surface Width | 4-49/64 in (12.11 cm) |
| Bridge Width | 4 in (10,16 cm) |
| Drum Mounting | Outboard |
| Height | 12 in (30.48 cm) |
| Hole Size | 15/16 in (2.39 cm) |
| Overall Depth | 8-57/64 in (22.59 cm) |
| Pilot Diameter | 9 in (22.86 cm) |
| Type | X30 Balanced |
| VMRS Code | 013-017-006 |
| Weight | 66 to 70 lbs |
| Weight (lbs) | 29.94 kg (66 lb) |
| Wheel Type | Disc |
| Width | 18 in (45.72 cm) |
Interchanges & Equivalent parts:
| 53-123575 |
| 151.5408BA-LW |
| 20421880 |
| 53-123575-002 |
| 53123575002-RI |
| 8235-53123575002 |
| ATI53123575002 |
| DW123575 |
| GUN 3741X |
| GUN 9016X |
| HWI 88870BK |
| TDA 53 123575 002 |
| TDA53123575002 |
