Brake Drum, 16-1/2 in x 7 in, 10 holes, (114 lb)

#GUN3120

Product Overview

This 16.5 in x 7 in brake drum is designed for truck and trailer axles with a 22,500 lb axle capacity. It features 10 bolt holes, an outboard mounting, and a durable cast construction for reliable braking performance.

Features & Benefits

All Gunite Brake Drums & Disc Brake Rotors Are Fully Protected by One of the Industrys Most Comprehensive Warranties on Material and Workmanship.

Manufactured to Meet or Exceed O.E.M. Specifications in Function. Form & Fit.

Gunite Brake Drums & Disc Brake Rotors Are Available Nationwide Through Over 400 Independent Warehouse Distributors. and Various O.E.M. Dealer Networks.

Gunite Brake Drums & Rotors Offer a Level of Engineering Quality That Meets or Surpasses the Requirements of Every Truck & Trailer Manufacturer.

Gunite Offers the Industry's Most Complete Line of Brake Drums & Disc Brake Rotors.

Specifications

Capacité de l'essieu (lb)	49 604 kg (22 500 lb)
Diamètre du cercle de perçage	11-1/4 po (28,58 cm)
Trou de boulon (nombre)	10
Largeur de segment de frein	7 po (17,78 cm)
Dimension du frein	16-1/2 po x 7 po
Diamètre de la surface du frein	16-1/2 po (41,91 cm)
Largeur de la surface de freinage	7-33/64 po (19,1 cm)
Largeur de cloison	7 po (17,78 cm)
Montage du tambour	Extérieur
Type de tambour	BDA
Profondeur d'encastrement du pare-poussière (C)	27/64 po (1,08 cm)
Dust Shield Recess Diameter (B)	17-49/64 po (45,13 cm)
Hole Size	27/32 po (2,15 cm)
Maximum Diameter	16-5/8 po (42,23 cm)
Overall Depth	10-47/64 po (27,27 cm)
Overall Diameter	18-49/64 po (47,67 cm)
Packaging	Individuel / En vrac
Pilot Diameter	9-7/16 po (23,98 cm)
Sidewall Offset (N)	3-19/64 po (8,38 cm)
Squealer Band Width (K)	2 po (5,08 cm)
VMRS Code	013-017-006
Weight	111 à 115 lb
Weight (lbs)	52,32 kg (114 lb)
Wheel Type	Disque
