Brake Drum, 16-1/2 in x 7 in, 10 holes, (93,7 lb)
#ROC53123537002
Features & Benefits
- Provides consistent braking performance under heavy loads
- Precisely machined for smooth and reliable braking operation
- Designed to OE specifications for a perfect fit and function
- Minimizes brake fade for increased safety during sudden stops
- Durable cast iron construction ensures long-lasting performance
- Resistant to heat, ideal for high-temperature braking conditions
- Reduces noise and vibrations for a comfortable driving experience
- Corrosion-resistant coating for enhanced longevity and aesthetics
Specifications
| Application | Truck Rear Axles. Trailer Axles |
| Axle Capacity (lb) | 50707 kg (23000 lbs) |
| Back Plate Thickness | 31/64 in (1.23 cm) |
| Balanced or Unbalanced | Balanced |
| Bolt Circle Diameter | 11-1/4 in (28.58 cm) |
| Bolt Hole (Number) | 10 |
| Brake Shoe Width | 7 in (17.78 cm) |
| Brake Size | 16-1/2 in x 7 in |
| Brake Surface Diameter | 16-1/2 in (41.91 cm) |
| Brake Surface Flat | 8-25/32 in (22.31 cm) |
| Brake Surface Width | 7-7/8 in (20.01 cm) |
| Bridge Width | 7 in (17,78 cm) |
| Drum Mounting | Outboard |
| Drum Mount Type | Outboard |
| Drum Type | BEA |
| Dust Shield Recess Depth (C) | 21/32 in (1.67 cm) |
| Dust Shield Recess Diameter (B) | 17-1/2 in (44.45 cm) |
| Flange Thickness | 31/64 in (1.23 cm) |
| Height | 12 in (30.48 cm) |
| Hole Size | 1 in (2.54 cm) |
| Maximum Diameter | 16-5/8 in (42.23 cm) |
| Overall Depth | 10-3/8 in (26.36 cm) |
| Overall Diameter | 18-7/8 in (47.95 cm) |
| Pilot Diameter | 8-25/32 in (22.31 cm) |
| Sidewall Offset (N) | 2-41/64 in (6.71 cm) |
| Squealer Band Width (K) | 1-59/64 in (4.89 cm) |
| Type | X30 Balanced |
| VMRS Code | 013-017-006 |
| Weight | 91 to 95 lbs |
| Weight (lbs) | 42.51 kg (93.7 lb) |
| Wheel Type | Disc |
| Width | 7 in (17.78 cm) |
Interchanges & Equivalent parts:
| 89996B |
| 1652871C1 |
| 3188224 |
| 53-123537 |
| 53123537 |
| 53123537002-RI |
| 80000-018 |
| ATI53123537002 |
| DW123537 |
| DW53123537 |
| GUN 3600A |
| GUN 3600AX |
| GUN 9006X |
| MER53-123537-002 |
| TDA 53 123537 002 |
| TDA 53123537 |
| TDA53123537002 |
| 69996B |
| 60864 |
| 60864B |
| 151.6700BA-LW |
| 17QJ3260 |
| 17QJ4116 |
| 17QJ4123 |
| 35763537 |
| 8235-53123537002 |
| 8HA431 |
| DB1657B |
| RW53-123537-002 |
| GUN3600A |
| KIC80002-018 |
| MOT89996B |
| SBR89996B |
| STE89996B |
| 8000018 |
| 54213018 |
| PP1601B |
| 1516700BA |
| 1516700BALW |
| 54261018 |
| 123207 |
| 107150 |
| OTR1602B |
| 66884F |
| 80002-018 |
| 4098040C1 |
| 123404 |
| 3600AX |
| 10009830 |
| 66864F |
| 3922 |
| 9006X |
| 1516501BA-LW |
| 10030774 |
| 3600A |
| 10001776 |
