Tambour de frein, 16-1/8 po x 8-5/8 po, 5 & 10 holes, (126,57 lb)
#WEB74089P
Caractéristiques et avantages
- Backed by a nationwide warranty and the best product support in the business
- Webb Wheel Products is your OE first-fit and aftermarket heavy-duty wheel-end component parts leader
- Manufactured in IATF 16949 or ISO 9001 registered facilities
Spécifications
| Back Plate Thickness | 5/8 po (1,59 cm) |
| Diamètre de cercle de boulonnage | 13-3/16 po (33,5 cm) |
| Bolt Hole (Number) | 5 and 10 |
| Brake Shoe Width | 8,625 po (21,91 cm) |
| Taille de frein | 16-1/8 po x 8-5/8 po |
| Brake Surface Diameter | 16-5/32 po (41,04 cm) |
| Largeur de surface de frein | 9-1/8 po (23,18 cm) |
| Brake Surface Flat | 14-17/32 po (36,91 cm) |
| Drum Mounting | Extérieur |
| Drum Type | Outboard |
| Taille de trou | 15/16 po (2,39 cm) |
| Maximum Wear Diameter | 11.73 Hub Bore - Oversized Brake Surface Diameter |
| Mount | 16.155 |
| Notes | MAN Drive Axle 16.14 X 8.62 |
| Profondeur totale | 11-13/16 po (30,01 cm) |
| Diamètre de pilote | 14-17/32 po (36,91 cm) |
| Type | Moulé |
| Poids | 121 à 130 lbs |
| Poids (lb) | 57,42 kg (126,57 lb) |
| Largeur | 8-5/8 po (21,91 cm) |
