Turn Signal, Amber & Yellow, Rectangular
#TRL22002Y
Product Overview
22 Series, Incandescent, Yellow Rectangular, 1 Bulb, Side Turn Signal, 2 Screw, PL-3, Stripped End/Ring Terminal, 12V, Kit
Features & Benefits
- Features dual contact marker/clearance and side turn or auxiliary turn functions
- Mounts on surface of vehicle or with "
- L"
- bracket
- Red lamp should be used for rear vehicle applications
Specifications
| Couleur | Jaune |
| Taille commune | 2 in (5.08 cm) |
| Contient | Lampe, Prise |
| Major actuel | 2,1 amp |
| Mineure actuelle | 0,49 amp |
| Profondeur | 2-13/32 in (6.12 cm) |
| Hauteur | 2-13/32 in (6.12 cm) |
| Trousse (O/N) | Yes |
| Matériau de la lentille | Polycarbonate |
| Matériel | Polycarbonate |
| Type de support | Montage par vis |
| Nombre de câbles | 3 |
| Fiche #1 | PL-3, Female |
| Fiche #2 | PL-2 (Stripped End) |
| Position | Side |
| Réfléchissant (O/N) | Non |
| Séries | 22 Series |
| Forme | Rectangle |
| Standard | FMVSS 108, NSVAC 108, DOT, SAE |
| Technologie | Incandescent |
| Type | Turn Signal |
| Code VMRS | 034-003-081 |
| Volt | 12V |
| Largeur | 5-15/16 in (15.09 cm) |
| Calibre de(s) fil(s) | 16 ga |
Interchanges & Equivalent parts:
| 52005005 |
| 810670 |
| 841322002Y |
| 66905 |
| HT50602220 |
| TL22002Y |
| TLD22002Y |
| TRU22002Y |
| MTL0220200Y |
| 16511933 |
| 22002Y |
| TL-22002Y |
| 22002Y-TL |
| 810677 |
| 8413-22002Y |
| 85106723 |
| LIT22002Y |
| PT2210A-KIT |
| TL 22002Y |
| TL 22002Y |
| TKL22002Y |
| 53063 |
| GRT53063 |
