Brake Drum, 15 in x 4 in, 5 & 6 holes, (62 lb)
#DRMX60452B
Product Overview
This 15 in x 4 in balanced brake drum is designed for truck front axles and transit vehicles. It features 5 or 6 bolt holes, an inboard design, and a durable cast construction for reliable braking performance.
Features & Benefits
- Manufactured to Meet or Exceed O.E.M. Specifications in Function. Form & Fit.
Specifications
| Application | Truck Front Axles. Transit |
| Back Plate Thickness | 1/2 in (1.27 cm) |
| Balanced or Unbalanced | Balanced |
| Bolt Circle Diameter | 11-1/4 in (28.58 cm) |
| Bolt Hole (Number) | 5 & 6 |
| Brake Shoe Width | 4 in (10.16 cm) |
| Brake Size | 15 in x 4 |
| Brake Surface Diameter | 15 in (38.1 cm) |
| Brake Surface Width | 4-7/16 in (11.28 cm) |
| Drum Mounting | Inboard |
| Drum Type | ABG |
| Dust Shield Recess Depth (C) | 25/32 in (1.99 cm) |
| Dust Shield Recess Diameter (B) | 15-51/64 in (40.13 cm) |
| Hole Size | 25/32 in (1.99 cm) |
| Maximum Diameter | 15-1/8 in (38.42 cm) |
| Notes | Machine to Balanced |
| Overall Depth | 5-27/32 in (14.85 cm) |
| Overall Diameter | 17-13/32 in (44.22 cm) |
| Packaging | Individual / Bulk |
| Pilot Diameter | 9-1/4 in (23.5 cm) |
| Sidewall Offset (N) | 1-19/64 in (3.3 cm) |
| Squealer Band Width (K) | 1-23/32 in (4.37 cm) |
| Type | Cast |
| VMRS Code | 013-017-006 |
| Weight | 61 to 65 lbs |
| Weight (lbs) | 28.13 kg (62 lb) |
| Wheel Type | Spoke |
| Width | 4 in (10.16 cm) |
Interchanges & Equivalent parts:
| 100222 |
| 100222B |
| 122104 |
| 3057 |
| 3057A |
| 3057B |
| 3057F |
| 3760BX |
| 65514B |
| U00X60452 |
| X60452 |
| X61337B |
| 54207018 |
